Ultra High Precision Coulometry UHPC 20A Channel Module
Novonix
Reliable, high precision & rapid data analysis
NOVONIX™ UHPC systems use specifically designed channel modules that address a wide range of current measurement, providing the reliable, high precision, and rapid data analysis that our customers value. When used with a properly controlled temperature, these systems can measure Coulombic Efficiency with better precision than any other system on the market.
All NOVONIX Channel Modules come with a CE mark, certified to IEC 62368-1:2018 for safety and emissions. Where required, products can be UL/CSA marked.
NOVONIX’s industry leading Ultra-High Precision Coulometry (UHPC) Channel Modules accurately measure and control current and voltage, with high precision and low noise, providing better quality data that allow for greater confidence.
SOURCE
Current
Range: 2A, 20A
Resolution: <20ppm FSR
Accuracy: 0.01% FSR
Noise: 0.002% FSR
Temperature Coefficient: 0.002% FSR over 23 ±5°C
Voltage
Range: 0V-5V
Resolution: <50μV
Accuracy: 200μV
Noise: 100µV
Temperature Coefficient: 0.002% FSR over 23 ±5°C
MEASUREMENT
Current
Resolution: <20ppm
Accuracy: 0.005% FSR
Noise: 0.002% FSR
Temperature Coefficient: 0.002% FSR over 23 ±5°C
Voltage
Resolution: 1μV
Accuracy: 200μV
Noise: 100µV
Temperature Coefficient: 0.002% FSR over 23 ±5°C
TIMING
Resolution: 10ms
Measurement Frequency: 6Hz
Accuracy: 2ppm
INTEGRATED RTD TEMPERATURE SENSING
Resolution: ±0.01°C
Accuracy: ±0.5°C
Noise: ±0.05°C
TECHNICAL CONSIDERATIONS*
Dimensions WxHxD (In): 19” x 3.5” x 28”
Rack Space (U): 2U
Weight (lbs): 34
Number of Test Channels: 4
ench and Rack Mountable?: Yes
Power Draw (VA): 1500VA
Voltage: DC Voltages Supplied by Power Module
Minimum Discharge Voltage: 0.005V
Required Lab Temperature
Range: 18°C – 28°C
Required Lab Temperature
Stability: ±1°C
*Specifications calculated based on theoretical electronic values in a controlled calibration lab setting using precision resistor elements, not live cells. For best performance, we
recommend pairing Channel Modules with NOVONIX Thermal Chambers, which are specifically designed to provide the temperature stability required for UHPC experiments.
