Compact Disassembling Cutter for 18650 Cylindrical Cases (Optional for 21700, 26650 or 32650) - MSK-530

MSK-530 is a compact manually-operated machine for disassembling cylinder cases in the battery R&D lab. The compact body design allows easy operation inside a glove box to preserve & prevent the electrolyte and active materials from contamination during case disassembling. Simple operation with a safety protection cover allows customers to master the disassembling procedure within 5 minutes.

SPECIFICATIONS:

Supply Voltage	DC24V  (a 110~240VAC to 24VCD power adapter is included)
Power	100W
Slicing Motor Speed	1000 rpm
Die Rotating Speed	1000 rpm
Micrometer Accuracy	0.05mm
Warranty	One year limited with lifetime support (Consumable part such as the cutting blade is not under the coverage of warranty) Parts rusted without regular cleaning and maintenance are not covered by the warranty
Product Dimensions	590(L) x 300(W) x 230 (H) Lid Closed, mm  590(L) x 300(W) x 460 (H) Lid Open, mm
Accessories	Standard disassembling die for 18650 cases. 5 pcs carbide cutting blades are included. ( click picture left to order spare ) Additional die sets are available for 26650, 32650  as options. Cutter for 4680 - 46120 is available upon request at the extra cost Additional blade and pin wrench for changing blades are available upon request.
Net Weight	35 kg
Shipping Weight & Dimensions	100 lbs; 40"x20"x20"
Application Notes	MTI also provides MSK-510M series for cylinder case sealing, please order separately from related products below.
Attention	Considering the best interest of the blade's service life, low feeding speed is suggested. Normally, 45 seconds is needed to cut through the cylinder casing.
