AvCarb  |  SKU: 18070017

AvCarb GDS2120

€0,00
Size (cm)

Delivery and Shipping to EU

We will add in the quotation, the shipping, insurance, customs clearance costs.

AvCarb GDS2120

AvCarb

AvCarb Material Solution’s Gas Diffusion System GDS2120 P75 combines AvCarb's proprietary carbon fiber paper, a PTFE treatment, and micro-porous layer coating, designed for the rigorous demands of specific fuel cell applications such as PEMFC, DMFC, and PAFC.

AvCarb P75 is the base substrate used in GDS2120.



AvCarb Gas Diffusion Systems (GDS) Carbon Paper Properties Sheet

AvCarb Gas Diffusion Systems (GDS) Carbon Paper Selection Guide



AvCarb Gas Diffusion Systems Properties
Material Type Carbon Fiber Paper
Base Material AvCarb P75
Nominal Thickness (@ 5.00 N/cm²) .248 mm (248 microns)
Nominal Base Weight 101 g/m²
Break Strength machine direction 25 MPa
Break Strength cross machine direction 15 MPa
Stiffness machine direction 21.0 Taber
Stiffness cross machine direction 14.7 Taber
Bulk Density (@ 0.68 N/cm² / 1psi) 0.40 g/cm3
Compressibility ((22N - 113N)/22 x 100%) 11.0%
Through-Plane Resistivity <14.0 mOhm*cm²
PTFE Treatment Yes
Microporous Layer (MPL) Yes, on one side
