Automated Pellet Pressing System up to 6 sample and 8 ton - AM-YLJ-8T

€0,00

Delivery and Shipping to EU

We will add in the quotation, the shipping, insurance, customs clearance costs.

Automated Pellet Pressing System up to 6 sample and 8 ton - AM-YLJ-8T

MTI

AM-YLJ-8T is an automated pallet pressing system for high-throughput and autonomous experiments in condensed phase. This compact, glovebox-friendly unit is programmable via an LCD touchscreen and compatible with various types of powder in a fast and accurate manner for powder palletization. The modular design can be used solely for 6 samples per batch or pairs with automated MTI materials preparation system for autonomous experiments. The free software advances instrumental communication and data acquisition.


SPECIFICATIONS:
Operation procedures
  • Program operation procedure in PC or touchscreen - including pressing pressure and holding time
  • Manual load powders into 6 clean pressing dies. and start the program.
  • The system
    • Place the top pressing rod
    • Move the pressing die for pressing and dwelling
    • Take out the sample via a demolding process
    • Place the sample inside a clean plastic cup.
  • Throughput: 30 minutes per 6 samples.
 Dry pressing die
  • Material: Tool Steel (HRC60-62)
  • Standard: 6 sets of 10 mm diameter dies are included
  • Max pressure: 1000 MPa, 8 ton-force
Compliance
  • CE Certified
  • NRTL certification is available upon request at the extra cost of $3500.00
