FCS | SKU:
11044001
Electrolyzer MEA - 3 Layer
Regular price
€0,00
Unit price
/
Unavailable
Couldn't load pickup availability
Delivery and Shipping to EU
Delivery and Shipping to EU
We will add in the quotation, the shipping, insurance, customs clearance costs.
Electrolyzer MEA - 3 Layer
FCS
Electrolyzer Membrane Electrode Assemblies (MEA) for high efficiency production of Hydrogen and Oxygen. These brand of Electrolyzer MEAs are used by many as their “gold standard” when designing new Electrolyzer products. These particular type of Electrolyzer MEAs are 3-layer configurations, or Catalyst Coated Membrane (CCM), designed to provide some of the highest efficiencies and purest hydrogen via electrolysis. Custom sizes and configurations are also available with no minimum order quantities and rapid lead times.
| Active Area | Membrane Area |
| 2.2cm x 2.2cm | 10.0cm x 10.0cm |
| 5.0cm x 5.0cm | 10.0cm x 10.0cm |
| 7.1cm x 7.1cm | 12.0cm x 12.0cm |
| 10.0cm x 10.0cm | 12.0cm x 12.0cm |
| MEA Properties | |
| MEA Type | Electrolyzer |
| Membrane Type | PFSA Membrane |
| Membrane Thickness | 127 micrometers (5 mil) |
| Anode Loading | 3.0 mg/cm² |
| Anode Catalyst | Iridium Ruthenium Oxide |
| Cathode Loading | 3.0 mg/cm² |
| Cathode Catalyst | Platinum Black |
| Gas Diffusion Layer | None |
