1100°C Vacuum Crucible Furnace with 4"OD x 8" H Quartz Chamber - VBF-1200S-VC

Processing Tube and flange

•  The quartz tube with one end closed and a flange and valve is inserted into the heating chamber for processing under a vacuum
• Quartz tube dimension: 100mm OD x 94 mm ID x 250 mmL
• One flange with 1/4" gas inlet and needle valve, KF 16 port ( to install a vacuum gauge), and KF 25 port ( to connect to a vacuum pump, as well as KF25 Vacuum Right-Angle Valve  are included
• Optional: KF-16 could be used on the Anti-Corrosive Digital Vacuum and bellow tube can be order by click the picture below:

Vaccun level: 10-2 torr by mechanical pump and 10-5 torr vy turbo pump



 Max. Temperature

 Max. Heating Rate

• 20 °C /min Max.

 Temperature controller

• Two digital temperature controller is built a separate box with +/- 1ºC accuracy
• One controller and T/C is for controlling
• PID automatic control and auto-tune function.
• 30 programmable segments for precise process
• Built-in protection for over-heated and broken Thermal couple.
• Another one is for monitoring furnace running and cut-off power if the furnace overheated
• Two Omega K-type thermal couples included
• RS485 port installed for PC operation

• CE Certified
• NRTL Certification is available upon request, additional charges will apply
