20T Max. Horizontal Servo-Motor Driven Crushing & Nail Penetration Tester with Digital Control - MSK-TE935

• 208- 240VAC, 3 phases, 50/60Hz
• 10KW
• 380VAC version is available upon request

• Force 1000N~200KN with Accuracy: ±1%
• Pressing Head:  R75 mm included (customized head is available upon request)
• Crushing speed: 1- 40 mm/s adjustable via hydraulic pump's valve
• Programmable Battery Height Range: 0- 400 mm
• 4 channels Voltage measurements: 2 channel 0 - 10V & 2 channel 0 - 100V
• 4 channel temperature measurements: 01300, accuracy: ±0.1

• Driven by Servo-motor
• Penetration Force: adjustable
• Penetration speed: 1~40 mm/s adjustable  (High speed up to 130 mm/s is available upon request)
• Dwell time: 0~9999s adjustable
• Four nails included: ?5mm?6mm?7mm?8mm made by high-temperature steel

• Double-layer steel chamber for anti-explosion
• Inside chamber: made of 1.5 mm thickness cold rolled SS304  with tensile strength > 500 Mpa
• Outside casing: made of 1.5 mm thickness annealed A3 steel with Tensile strength > 400 Mpa
• Explosion-proof window: 280X 280mm
• Double layer 5 mm thick anti-explosion glass with double sides anti-explosion film to ensure broken glass can not flying out in the case of explosion
• Laser crosshair for visualizing crushing / penetrating center
• Battery Placement Area: L 600mm x W 600mm x H 400mm
• Lighting is built on top
• Four-wheel is installed on the bottom to make the box movable

Fire extinguishing apparatus (optional)

• Two fire detectors are installed inside the chamber, which will relay on to open optional Fire extinguishing apparatus once fire happen upon request of the customer
• Customers may use the detector drive water valve opening or drive Fire extinguisher open according to battery type
• We may add other Fire extinguishing apparatus upon request of the customer

• Separated control unit from the operation chamber
• Touch screen panel for parameter and programma setting
• Optional: Remote operation by PC via WiFi network is available upon request at an extra cost

• Explosion-proof box: W 800mm x D 900mm x H 2015mm
• Weight: 450Kg

• CE certified
• NRTL certification is available upon request.
•

• The Machine must be put in the isolated fire-proof room or  fume-hood with venting and extinguishing system
• Please use remote for operation in our site room
