Compact Graphitization Furnace (up to 2800) GSL-2800X-GRF

GSL-2800X-GRF is a high-temperature graphitization furnace up to 2800°C using graphite heating elements. It comes with multiple layers of graphite felt thermal insulation and a water-cooled stainless steel chamber. The equipment also features a bottom-loading sample stage for easy sample loading and retrieval. The chamber has a vacuum pressure rating <1e-5 torr with an optional turbo pump.

SPECIFICATIONS Power 480VAC, 3 phase, 60Hz, 40kW 380VAC, 3 phase, 50Hz, 40kW is also available upon request.  Vacuum Chamber Water-cooled stainless steel 304 vacuum chamber. Inner dimensions: Ø360 x 480 mm Water-cooled graphite electrode feedthrough 3-5 layers of graphite felt thermal insulation Water flow and overtemperature interlocks Heating Element (Graphite) Effective heating area: Ø100 × 260 mm Sample size: <Ø80 × 200 mm Cylindrical graphite heater, up to 2800°C  Graphite Heater  Temperature Control Eurotherm 3000 series temperature controller with dual inputs 28-segment programmable PID loop Dual temperature probes RT - 2000°C C-type thermocouple 2000<T<2800°C Dual color Micron-epsilon Pyrometer Temperature uniformity ±8°C in Ø80×180 mm Temperature stability: ±1°C  Heating Rate: ?10°C/min RT - 1000ºC ?15°C/min 1000 - 1600ºC ?10°C/min 1600 - 2000ºC ?5°C/min 2000 - 2200ºC ?1°C/min 2200 - 2800ºC ?0.5°C/min Remote temperature control and monitoring via an RS485 port.  Sample Stage Motorized bottom-loading sample stage for easy sample loading and retrieval.  Graphite crucible: Ø95×Ø75×70 mm  Utilities (Request but not included) Water Chiller with a cooling capacity of 8kW Water flow rate 50L/min Dimensions: 830mm x 650mm x 1170mm ( L x D x H) Roughing pump with a particle foreline trap  MTI recommends to get the water chiller and vacuum pump shown below   Water Chiller      Vacuum Pump Reference Video Warranty One-year limited manufacturer warranty with lifetime support. Consumable parts such as heating elements, thermocouples, and graphite insulation are not covered by the warranty.  Compliance CE Certified NRTL certification is available upon request at an extra cost
