MTI | SKU: KSL-1100X-S-UL-110V

Glove Box Compatible Tube Furnace upto 1100C - GSL-1100X-S

€0,00

Rated Voltage

110V AC

Delivery and Shipping to EU

We will add in the quotation, the shipping, insurance, customs clearance costs.

Glove Box Compatible Tube Furnace upto 1100C - GSL-1100X-S

MTI

GSL-1100X-S is a 1100^oC tube furnace with small foot-print, low weight and low power requirement. It can be easily accommodated in a glove box for material synthesis which vacuum or specific gas conditions.

SPECIFICATIONS:

Furnace Construction	High purity fibrous alumina insulation for maximum energy saving - 30% less power consumption than other brands click pic below -left to order spare ) Door drops down for easy and safe sample loading and unloading (with automatic power off when the door is opened). (Optional) Two 8 mm diameter hose barb connectors (gas inlet and outlet) (see pic below) in the furnace back panel are available at extra cost ($99 for both connectors). Check the option box. Note: Self-Installation is required. The open barb-holes and threaded holes are ready before shipping.
Chamber Size	Size: 4"x4"x4" or 100x100x100 mm Capacity: 65 cubic-inch or 1 liter Click on picture to see the chamber size
Power	110V version: 950 W ( power cord is included ) 220V version: 1.2KW
Voltage	AC 110V or AC 220V 50/60 Hz -- please select the voltage in the option bar
Max. Temperature	1200 °C (< 1 hour)
Continuous Working Temperature	1100 °C
Max. Heating Rate	30 °C /min
Temperature Controller	PID automatic control and auto-tune function. 30 programmable segments for precise control. Built in protection for the over-heating and broken thermocouple. Large digital control panel (48 x 96 mm) for easy operation.
Temperature Accuracy	+/- 1 °C
Heating Elements	Fe-Cr-Al Alloy doped by Mo
Thermocouple	K type
Overall Dimensions	200 x 230 x 360 mm Click on picture to enlarge and view details
Net Weight	~ 8Kg
Shipping Dimensions	17"(L) x14"(W) x 18"(H)
Shipping Weight	40 lbs
Warranty	One year limited warranty with lifetime support *ATTENTION: Any damages caused by the use of corrosive and acidic gases are not under the coverage of MTI One Year Limited Warranty.*
Compliance	CE Certified All electric components ( >24V) are UL / MET / CSA certified The furnace is ready to pass TUV(UL61010) or CSA certification at extra cost. please click marks below to learn details )
Application Notes	For preserving the longevity of the furnace components, we recommend the heating rate not to exceed 10 °C /min. The cooling rate shall also not exceed 10 °C /min. Toxic or explosive gases are not recommended for use with this furnace without necessary safety controls and supervision. Please put furnace into fume hood for better safety ( click picture left ) Small cracks may appear on the surface of the refractory ceramics over extended use. This is a normal occurrence and the cracks may be repaired with alumina coating. May put the small furnace into a standard glovebox via airlock chamber and fire sample under inert gas.
