Cell-Anout

Ivium Technologies

 Analog output signal module for cell connector



Product description

The Cell-Anout module allows an analog output signal to be sent from an instrument, without the need for a peripheral port. This brings extra functionality to instruments such as the dModules in the Ivium-n-Stat and the pocketSTAT2/Vertex.One/Vertex.C.

The module connects between the instrument and the cell cable. Screw contacts (analog output and GND) allow the connection to the input to external equipment, e.g. the analog input of the RRDE to control the rotation speed.

Technical specifications

  • Powered from the cell connector
  • Output range is ±10V (20bit) between the + and – input
  • Should only be used on high resistive inputs
  • Output current: max. 1mA
