G-HFCS (Hydrogen Fuel Cell Power Generator)
Thasar S.r.l.
The new hydrogen fuel cell product line is the ideal alternative to the standard portable power generators which use diesel or batteries. Easy to use and with a smart and compact design, G-HFCS-10W6V hydrogen fuel cell system produces 10 W of nominal power and brings you full energy independence for various small and portable applications that require power in the range of 0-10 Watts. You can charge your smartphone, radios, small fans, Bluetooth headphones, small portable cameras, LED flashlights, small battery modules, various camping devices, and many more other portable devices. A controller module that manages the startup, shutdown, and all other standard functions of the fuel cell system is included in the kit. A DC/DC converter will be required to convert the fuel cell power into the desired voltage and current values.
This portable fuel cell system can be easily connected with a high purity hydrogen source such as a compressed cylinder from a local gas supplier, hydrogen stored in a composite tank, or a compatible hydride cartridge to get the best performance.
Colonna1 |
10 W | 20 W | 100 W | 200 W | 600 W | 1000 W | 2000 W | 3000 W | 5000 W |
| Nominal Power | 10 W | 20 W | 100 W | 200 W | 600 W | 1000 W | 2000 W | 3000 W | 5000 W |
| Operating Voltage Range | 5 - 9 V | 10 - 18 V | 10 - 18 V | 20 - 37 V | 20 - 37 V | 30 - 56 V | 40 - 74 V | 35 - 63 V | 55 - 99 V |
| Operating Current Range | 0 - 2.7 A | 0 - 2.7 A | 0 - 9.6 A | 0 - 9.6 A | 0 - 31 A | 0 - 37.2 A | 0 - 56.4 A | 0 - 90 A | 0 - 90 A |
| Efficiency | >40% | >40% | >40% | >40% | >40% | >40% | >40% | >40% | >40% |
| Hydrogen Purity | >99.99% (CO content being <1 ppm) | >99.99% (CO content being <1 ppm) | >99.99% (CO content being <1 ppm) | >99.99% (CO content being <1 ppm) | >99.99% (CO content being <1 ppm) | >99.99% (CO content being <1 ppm) | >99.99% (CO content being <1 ppm) | >99.99% (CO content being <1 ppm) | >99.99% (CO content being <1 ppm) |
| Hydrogen Pressure | 0.035 - 0.05 MPa | 0.035 - 0.05 MPa | 0.035 - 0.05 MPa | 0.035 - 0.05 MPa | 0.035 - 0.05 MPa | 0.035 - 0.05 MPa | 0.035 - 0.05 MPa | 0.035 - 0.05 MPa | 0.035 - 0.05 MPa |
| Hydrogen Consumption | ~210 mL/min (at 2.7 A) | ~420 mL/min (at 2.7 A) | ~1500 mL/min (at 9.6 A) | ~3000 mL/min (at 9.6 A) | ~9600 mL/min (at 31 A) | ~17 L/min (at 37.2 A) | ~35 L/min (at 56.4 A) | ~49 L/min (at 90 A) | ~77 L/min (at 90 A) |
| Operating Temperature | non-freezing to 35 ºC | non-freezing to 35 ºC | non-freezing to +35 ºC | non-freezing to 35 ºC | non-freezing to 35 ºC | non-freezing to 35 ºC | non-freezing to 35 ºC | non-freezing to 35 ºC | non-freezing to 35 ºC |
| Ambient Humidity | 10% RH to 90% RH (No misting) | 10% RH to 90% RH (No misting) | 10% RH to 90% RH (No misting) | 10% RH to 90% RH (No misting) | 10% RH to 90% RH (No misting) | 10% RH to 90% RH (No misting) | 10% RH to 90% RH (No misting) | 10% RH to 90% RH (No misting) | 10% RH to 90% RH (No misting) |
| Storage Temperature | non-freezing to 60 ºC | non-freezing to 60 ºC | non-freezing to 60 ºC | non-freezing to 60 ºC | non-freezing to 60 ºC | non-freezing to 60 ºC | non-freezing to 60 ºC | non-freezing to 60 ºC | non-freezing to 60 ºC |
| Stack Dimensions | 51.5*47*51.5mm | 51.5*47*87mm | 94*78*91mm | 95*78*162mm | 145*162*170mm | 145*162*261mm | 152*202*315mm | 198*262*287mm | 198*262*429.5mm |
| Weight | ~160 grams | ~260 grams | ~630 grams | ~975 grams | ~3255 grams | ~4715 grams | ~6390 grams | ~10 kg | ~14 kg |
| Number of Cells | 10 Cells | 20 cells | 20 Cells | 40 Cells | 40 Cells | 60 Cells | 80 Cells | 70 Cells | 110 Cells |
Typical lead time of 6-8 weeks to be expected.
